Features
▪ Common solvents：toluene, acetonitrile,
hexane, ether, THF, DMF, methylene
chloroform
▪ Number of solvents：3, 5, 7
(Customized in terms of the requirements
of the user)
▪ Purification capacity per solvent is
~1200L（dependent on initial water content）
▪ Flow rate, up to 800 ml/min
▪ H2O<1PPM，O2<1PPM
Specifications
| Material | 304# stainless steel |
| Common Solvent | Toluene, acetonitrile, hexane, ether, THF, DMF, methylene chloroform etc. |
| Number of Solvent | 3, 5, 7 (Customized in terms of the requirements of the user) |
| Purification Capacity Per Unit | <1200L (Dependent on initial water content) |
| Flow Rate | Up to 800 mL/min |
| Technical Parameter | H2O<1 ppm, O2<1 ppm |
| Fluid Reservoir | 17L |
| Internal Material | Included dehydration and deoxygenization materials |
| Particle Filter | Equipped with particle filter |
| Gas Supply System | Included gas purifier |
| Working Gas | 99.99% N2-Ar |
| Gas Connection | One gas supply port for each solvent |
| Vacuum System | One dry pump |
| Explosion-proof Cabinet | Fire-proof cabinet for solvent purification system |
